3-31
3-7 Parameter List
3
Operation
Others
b086
Frequency
conversion
coefficient
0.1 to 99.9 1.0 Yes ⎯ 4-39
b087
STOP key
selection
00: Enabled
01: Disabled
00 No ⎯ 4-39
b088
Free-run stop
selection
00: 0 Hz start
01: Frequency pull-in restart
00 No ⎯
4-39
4-53
b089
Monitor display
selection
01: Output frequency monitor
02: Output current monitor
03: Rotation direction monitor
04: PID feedback value monitor
05: Multi-function input monitor
06: Multi-function output monitor
07: Frequency conversion monitor
01 Yes ⎯ 4-40
b091 Stop selection
00: Deceleration → Stop
01: Free-run stop
00 No ⎯ 4-39
b092 Cooling fan control
00: Always ON
01: ON during RUN
02: Depends on the fin temperature
01 No ⎯ 4-40
b130
Overvoltage LAD
stop function
00: Disabled
01: Enabled
00 No ⎯ 4-41
b131
Overvoltage LAD
stop function level
setting
200-V class: 330. to 395.
400-V class: 660. to 790.
380/
760
Yes V 4-41
b133
Overvoltage
protection function
selection during
deceleration
00: Disabled
01: Enabled
00 No ⎯ 4-35
b134
Overvoltage
protection level
setting during
deceleration
200-V class: 330. to 395.
400-V class: 660. to 790.
380/
760
No V 4-35
b140
Overcurrent
suppression
function
00: Disabled
01: Enabled
01 No ⎯ 4-42
b150
Automatic carrier
reduction
00: Disabled
01: Enabled
00 No ⎯
4-42
b15
1
R
eady function
selection
00: Disabled
01: Enabled
00 No ⎯ 4-42
Parameter
No.
Function name
Monitor or data range
(Digital Operator)
Default
setting
Changes
during
operation
Unit Page
* 2nd control is displayed when SET (08) is allocated to one of from C001 to C005.
