3-32
3-7 Parameter List
3
Operation
Multi-function input terminals
C001
Multi-function
input 1 selection
00: FW (forward)
01: RV (reverse)
02: CF1 (multi-step speed setting binary 1)
03: CF2 (multi-step speed setting binary 2)
04: CF3 (multi-step speed setting binary 3)
05: CF4 (multi-step speed setting binary 4)
06: JG (jogging)
07: DB (external DC injection braking)
08: SET (2nd control)
09: 2CH (2-step acceleration/deceleration)
11: FRS (free-run stop)
12: EXT (external trip)
13: USP (USP function)
15: SFT (soft lock)
16: AT (analog input switching)
18: RS (reset)
19: PTC (thermistor input)
20: STA (3-wire start)
21: STP (3-wire stop)
22: F/R (3-wire forward/reverse)
23: PID (PID enabled/disabled)
24: PIDC (PID integral reset)
27: UP (UP/DWN function accelerated)
28: DWN (UP/DWN function decelerated)
29: UDC (UP/DWN function data clear)
31: OPE (forced operator)
50: ADD (frequency addition)
51: F-TM (forced terminal block)
52: RDY (ready function)
53: SP-SET (special 2nd function)
64: EMR (emergency shutoff
*1
)
255: No function
*1. The EMR is set forcibly with switch S8, not
with parameters.
00
No ⎯ 4-43
C201
*2nd multi-function
input 1 selection
00
C002
Multi-function
input 2 selection
01
C202
*2nd multi-function
input 2 selection
01
C003
Multi-function
input 3 selection
18
C203
*2nd multi-function
input 3 selection
18
C004
Multi-function
input 4 selection
12
C204
*2nd multi-function
input 4 selection
12
C005
Multi-function
input 5 selection
02
C205
*2nd multi-function
input 5 selection
02
C011
Multi-function
input 1 operation
selection
00: NO
01: NC
00
No ⎯ 4-44
C012
Multi-function
input 2 operation
selection
00
C013
Multi-function
input 3 operation
selection
00
C014
Multi-function
input 4 operation
selection
00
C015
Multi-function
input 5 operation
selection
00
Parameter
No.
Function name
Monitor or data range
(Digital Operator)
Default
setting
Changes
during
operation
Unit Page
* 2nd control is displayed when SET (08) is allocated to one of from C001 to C005.
