Omron CPM1 Programming Manual

409
CQM1 Cycle Time and I/O Response Time Section 7-1
DBS 28.3 Constant ÷ word → word 2.5
62.4 Word ÷ word → word
136.4 *DM ÷ *DM → *DM
MBSL 94.0 Word × word → word 2.5
167.6 *DM × *DM → *DM
DBSL 86.3 Word ÷ word → word 2.5
160.4 *DM ÷ *DM → *DM
CPS 31.0 Comparing a constant and word 2.5
33.7 Comparing words
82.4 Comparing *DM
CPSL 51.3 Comparing words 2.5
102.6 Comparing *DM
NEG 41.3 Converting a constant → word 2.5
44.5 Converting a word → word
92.7 Converting *DM → *DM
NEGL 51.1 Converting a constant → words 2.5
103.2 Converting *DM → *DM
ZCP 38.2 Comparing a constant to a word range 2.5
44.7 Comparing a word to a word range
114.6 Comparing *DM to a *DM range
CPSL 77.7 Comparing words to a word range 2.5
151.4 Comparing *DM to a *DM range
XFRB 35.3 Transferring 1 bit between words with a constant for control
data
2.5
56.8 Transferring 1 bit between words with a word for control data
298.3 Transferring 255 bits between *DM with *DM for control data
PLS2 821.7 Words for control words 2.5
849.0 *DM for control words
ACC 547.3 Mode 0: Words for control words 2.5
577.0 Mode 0: *DM for control words
392.8 Mode 1: Words for control words
424.0 Mode 1: *DM for control words
404.8 Mode 2: Words for control words
430.3 Mode 2: *DM for control words
259.5 Mode 3: Words for control words
418.3 Mode 3: *DM for control words
SCL2 105.0 Word to word conversion, words for parameter words 2.5
179.8 *DM to *DM conversion, *DM for parameter words
SCL3 112.0 Word to word conversion, words for parameter words 2.5
186.8 *DM to *DM conversion, *DM for parameter words
Code Mnemonic ON execution
time (µs)
Conditions OFF execution
time (µs)

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
