419
CPM1/CPM1A Cycle Time and I/O Response Time Section 7-2
35 ORW 27.1 Constant V word word 5.6
28.7 Word V word word
70.7 *DM V *DM *DM
36 XORW 27.1 Constant V
word word 5.6
28.7 Word V
word word
70.5 *DM V
*DM *DM
37 XNRW 27.0
Constant V
word word
5.6
28.6
Word V
word word
70.5
*DM V
*DM *DM
38 INC 17.9 When incrementing a word 5.5
31.9 When incrementing *DM
39 DEC 18.3 When decrementing a word 5.5
32.3 When decrementing *DM
40 STC 6.3 Any 5.5
41 CLC 6.3 5.5
46 MSG 21.5 With message in words 5.5
35.7 With message in *DM
50 ADB 30.5 Constant + word word 5.6
32.1 Word + word word
73.9 *DM + *DM *DM
51 SBB 30.9 Constant – word word 5.6
32.7 Word – word word
74.5 *DM – *DM *DM
52 MLB 34.7 Constant × word word 5.6
36.3 Word × word word
80.7 *DM × *DM *DM
53 DVB 35.1 Word ÷ constant word 5.6
36.7 Word ÷ word word
81.1 *DM ÷ *DM *DM
54 ADDL 48.9 Word + word word 5.6
94.7 *DM + *DM *DM
55 SUBL 48.9 Word – word word 5.6
94.7 *DM – *DM *DM
56 MULL 138.7 Word × word word 5.6
184.3 *DM × *DM *DM
57 DIVL 136.7 Word ÷ word word 5.6
181.3 *DM ÷ *DM *DM
60 CMPL 30.4 Comparing words 5.6
60.8 Comparing *DM
61 INI 112.0 Starting comparison via word 5.6
126.0 Starting comparison via *DM
48.0 Stopping comparison via word
48.0 Stopping comparison via *DM
120.0 Changing PV via word
128.0 Changing PV via *DM
46.0 Stopping pulse output via word
60.0 Stopping pulse output via *DM
62 PRV 62.2 Designating output via word 5.6
78.0 Designating output via *DM
Code Mnemonic ON execution
