Omron G5 Series User Manual

3 - 53
3 Specifications
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
3-3 Servomotor Specifications
3
3-3-3 Encoder Specifications
3-3-3 Encoder Specifications
Incremental Encoder Specifications
Item Specifications
Encoder system Optical encoder
20 bits
Number of output
pulses
Phases A and B: 262,144 pulses/rotation
Phase Z: 1 pulse/rotation
Power supply voltage 5 VDC±5%
Power supply current 180 mA (max.)
Output signal +S, –S
Output interface RS485 compliant

Omron G5 Series Specifications

General

Feedback	Incremental Encoder, Absolute Encoder
Communication	EtherCAT
Safety Function	STO (Safe Torque Off)
Protection Functions	Overvoltage, Undervoltage, Overcurrent
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
