Omron G5 Series - Decelerator (Backlash: 15 Arcminutes Max.)

2 - 7
2 Models and External Dimensions
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
2-2 How to Read Model Numbers
2
2-2-4 Decelerator (Backlash: 15 Arcminutes max.)
2-2-4 Decelerator (Backlash: 15 Arcminutes max.)
R88G-VRSF09B100CJ
Decelerator for G5-Series Servomotor
A
pplicable Servomotor Capacity
050
100
200
400
750
: 50 W
: 100 W
: 200 W
: 400 W
: 750 W
Backlash: 15 Arcminutes max.
Gear Ratio
05: 1/5
09: 1/9
15: 1/15
25: 1/25
Flange Size Number
B: 52
C: 78
D: 98
Backlash
C: 15 Arcminutes max.
Options
J: With key
