Omron G5 Series User Manual

4 System Design
4 - 12
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
R88D-KP20H
RT
NFB
S
Noise filter (*1)
123
456
E
NF
Ground to
100 Ω or less
3-phase 200 to 230 VAC, 50/60 Hz
Main circuit
contactor (*1)
PL
Servo error display
L1C
L2C
L1
L2
L3
OMNUC G5-series
(Pulse-train Input Type)
AC Servo Drive
ALMCOM
/ALM37
36
User-side
control
device
CN1
X
24 VDC
11
10
BKIR
BKIRCOM
XB
24 VDC
Control cables
OMNUC G5-series
(Pulse-train Input Type)
AC Servomotor
W
V
U
B
E
M
CN2
Encoder cables
Power cables
24 VDC
(*3)
(*2)
CN1
CN1
*1. Recommended products are listed in 4-3,
Wiring Confirming to EMC Directives.
*2. Recommended relay: MY relay by
OMRON (24-V) For example, MY2
relay by OMRON can be used with all
G5-series motors with brake because
its rated inductive load is 2 A (24 VDC).
*3. There is no polarity on the brakes.
*4. Models with a built-in Regeneration
Resistor (KP20H) have B2 and B3
shorted. When the amount of
regeneration is large, remove the
connection between B2 and B3 and
connect a Regeneration Resistor
between B1 and B2.
B1
B3
B2
(*4)
Regeneration
Resistor
Reactor
CNB
CNC
CNA
CNA
Ground to 100 Ω or less
X
XB
X
1MC
Surge suppressor (*1)
OFF ON
X
1MC
Main circuit
power supply
1MC

Omron G5 Series Specifications

General

Feedback	Incremental Encoder, Absolute Encoder
Communication	EtherCAT
Safety Function	STO (Safe Torque Off)
Protection Functions	Overvoltage, Undervoltage, Overcurrent
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
