Omron G5 Series User Manual

7 - 21
7 Parameter Details
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
7-3 Vibration Suppression Parameters
7
• Select the notch width of the second resonance suppression notch filter.
• Increasing the setting value widens the notch width. Normally, use the default set value.
• Set the notch depth of the second resonance suppression notch filter.
• Increasing the setting value shortens the notch depth and the phase lag.
• Set the notch frequency of the third resonance suppression notch filter.
• When set to 5,000, the notch filter function is disabled.
• Select the notch width of the third resonance suppression notch filter.
• Increasing the setting value widens the notch width. Normally, use the default set value.
• Set the notch depth of the third resonance suppression notch filter.
• Increasing the setting value shortens the notch depth and the phase lag.
• Set the notch frequency of the fourth resonance suppression notch filter.
• When set to 5,000, the notch filter function is disabled.
• Select the notch width of the fourth resonance suppression notch filter.
• Increasing the setting value widens the notch width. Normally, use the default set value.
• Set the notch depth of the fourth resonance suppression notch filter.
• Increasing the setting value shortens the notch depth and the phase lag.
Pn205
Notch 2 Width Setting
Setting
range
0 to 20 Unit – Default
setting
2 Cycle the
power supply
–
Pn206
Notch 2 Depth Setting
Setting
range
0 to 99 Unit – Default
setting
0 Cycle the
power supply
–
Pn207
Notch 3 Frequency Setting
Setting
range
50 to 5,000 Unit Hz Default
setting
5,000 Cycle the
power supply
–
Pn208
Notch 3 Width Setting
Setting
range
0 to 20 Unit – Default
setting
2 Cycle the
power supply
–
Pn209
Notch 3 Depth Setting
Setting
range
0 to 99 Unit – Default
setting
0 Cycle the
power supply
–
Pn210
Notch 4 Frequency Setting
Setting
range
50 to 5,000 Unit Hz Default
setting
5,000 Cycle the
power supply
–
Pn211
Notch 4 Width Setting
Setting
range
0 to 20 Unit – Default
setting
2 Cycle the
power supply
–
Pn212
Notch 4 Depth Setting
Setting
range
0 to 99 Unit – Default
setting
0 Cycle the
power supply
–
All
All
All
All
All
All
All
All

Omron G5 Series Specifications

General

Feedback	Incremental Encoder, Absolute Encoder
Communication	EtherCAT
Safety Function	STO (Safe Torque Off)
Protection Functions	Overvoltage, Undervoltage, Overcurrent
Vibration Resistance	4.9 m/s² (10 to 55 Hz)
