7 - 31
7 Parameter Details
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
7-4 Analog Control Parameters
7
Do not set.
Do not set.
Do not set.
Do not set.
Do not set.
Do not set.
Do not set.
Do not set.
Do not set.
Do not set.
Pn320 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
Pn321 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
Pn322 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
Pn323 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
Pn324 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
Pn325 Reserved
Setting
range
10,000 Unit Default
setting
10,000
Cycle the
power supply
Pn326 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
Pn327 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
Pn328 Reserved
Setting
range
16,000 Unit Default
setting
16,000
Cycle the
power supply
Pn329 Reserved
Setting
range
0 Unit Default
setting
0
Cycle the
power supply
