5-10 HS-360X Handheld DPM Scanner User Manual

User Preferences

Beeper Tone

Parameter # 145

To select a beeper tone, scan one of the following programming symbols.

Off

(3)

Low Tone

(2)

* Medium Tone

(1)

High Tone

(0)
