HS-360X Handheld DPM Scanner User Manual 9-105

Symbologies

BC412

Important: Decoder Effort must be set to Level 4 for the scanner to support BC412.

To enable or disable BC412, scan the appropriate symbol below.

Enable BC412

(1)

* Disable BC412

(0)
