HS-360X Handheld DPM Scanner User Manual 9-35

Symbologies

ISSN EAN

Parameter # 617

To enable or disable ISSN EAN, scan the appropriate programming symbol below.

Enable ISSN EAN

(1)

* Disable ISSN EAN

(0)
