HS-360X Handhel
d DPM Scanner User Manual
7-15
USB Interface
USB Keyboard FN 1 Substitution
This option applies only to
the USB HID Keyboard Emulation de
vice. When enabled, this
allows replacement of any FN 1 characters in an EAN-
128 barcode with a Key Category
and value chosen by the u
ser.
Enable FN1 Substitution
*
Disable FN1 Substituti
on
188
190
