HS-360X Handheld DPM Scanner User Manual 9-33

Symbologies

UCC Coupon Extended Code

Parameter # 85

Enable this parameter to decode UPC-A barcodes starting with digit ‘5’, EAN-13 barcodes

starting with digit ‘99’, and UPC-A/GS1-128 Coupon Codes. UPCA, EAN-13, and GS1-128

must be enabled to scan all types of Coupon Codes.

See UPC/EAN/JAN Supplemental Redundancy to control autodiscrimination of the

GS1-128 (right half) of a coupon code.

Enable UCC Coupon Extended Code

(1)

* Disable UCC Coupon Extended Code

(0)
