Chapter 3: Setup
Description Image
A Main carton
B Docking station carton
C Docking station filler. (Might con-
tain options.)
D Unloading ramp
E LD-250 cover carton
F LD-250
G Shipping base, with wheel chocks
H Protective filler (2)
I Foam corners (4)
J Plywood pallet
Figure 3-2 LD-250 Packaging
Unpack as follows:
1.
Make sure you have 1.5 m (5 feet) of clear working space around the pallet.
2.
Remove any weatherproof film or plastic sheet material and carefully cut the poly strap-
ping with a sharp safety blade.
20472-000 Rev B LD-250 Platform User's Guide 49
