H Setting the Motor Phase to neutral Resistance (n107)
·Set this parameter to 1/2 of the phase-to-phase resistance of the motor, or phase to
neutral resistance.
·Contact the manufacturer of the motor for the above resistance.
·This parameter is used asavectorcontrol constant. Be sureto setthe parameter cor-
rectly.
n107 Motor Phase to neutral
Resistance
Register 016B
Hex
Changes during
operation
No
Setting
range
0.000 to 65.50 (W) Unit of
setting
See
note 1
Default setting See
note 2
Note 1. The value will be set in 0.001-W increments if the resistance is less than 10 W
and 0.01-W increments if the resistance is 10 W or over.
Note 2. The default setting for this parameter is the standard phase to neutral resist-
ance of the maximum applicable motor.
H Setting the Motor No-load Current (n110)
·Set the motorno-loadcurrent in percentagebased on therated currentof the Inverter
as 100%.
·Contact the manufacturer of the motor for the motor no-load current.
·This parameter is used asavectorcontrol constant. Be sureto setthe parameter cor-
rectly. This set value is used for slip compensation as well.
n110 Motor No-load Current Register 016E
Hex
Changes during
operation
No
Setting
range
0 to 99 (%) Unit of
setting
1% Default setting See note
Note Thedefaultsettingforthis parameter is the standardno-loadcurrentofthemaxi-
mum applicable motor.
Basic Operation Chapter 5

Omron SYSDRIVE 3G3MV Specifications

General

Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1-400 Hz
Cooling Method	Forced Air Cooling
Communication Interface	RS-485
Model	Omron SYSDRIVE 3G3MV
Protection	Overcurrent, Overvoltage, Overheat
Ambient Temperature	-10 to 50°C
Overload Capacity	150% for 60 seconds
Storage Temperature	-20 to 65°C
Humidity	20 to 90% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	200-230V, 380-460V
