9-1 Inverter Specifications
H 200-V-class Inverters
3-phase
2
0
0
-
V
A
C
Model 3G3MV-
A2001 A2002 A2004 A2007 A2015 A2022 A2040 A2055 A2075
3
-
p
h
a
s
e
200-VAC
models
Power
supply
Rated
voltage and
frequency
3-phase 200 to 230 VAC at 50/60 Hz
Allowable
voltage
fluctuation
--15% to 10%
Allowable
frequency
fluctuation
±5%
Input
power
supply
capacity
0.4 0.9 1.6 2.7 4.3 5.9 9.3 13.3 17.6
Heat radiation (W)
(see note 2)
13.0 18.0 28.1 45.1 72.8 94.8 149.1 249.8 318.1
Weight (kg) 0.6 0.6 0.9 1.1 1.4 1.5 2.1 4.6 4.8
Cooling method Natural cooling Cooling fan
Single-
p
h
a
s
e
Model 3G3MV-
AB001 AB002 AB004 AB007 AB015 AB022 AB040 --- ---
S
i
n
g
l
e
-
phase
200-VAC
models
Power
supply
Rated
voltage and
frequency
Single-phase 200 to 240 VAC at 50/60 Hz
Allowable
voltage
fluctuation
--15% to 10%
Allowable
frequency
fluctuation
±5%
Input
power
supply
capacity
0.5 0.9 1.6 2.7 4.3 5.9 9.3
Heat radiation (W)
(see note 2)
14.1 20.0 31.9 51.4 82.8 113.6 176.4 --- ---
Weight (kg)
0.6 0.7 1.0 1.5 1.5 2.2 2.9 --- ---
Cooling method
Natural cooling Cooling fan
Max. applicable motor capacity
(kW)
0.1 0.25 0.55 1.1 1.5 2.2 4.0 --- ---
Output
specifi-
c
a
t
i
o
n
s
Rated output
capacity (kVA)
0.3 0.6 1.1 1.9 3.0 4.2 6.7 9.5 13
s
p
e
c
i
f
i
-
cations
Rated output
current (A)
0.8 1.6 3.0 5.0 8.0 11.0 17.5 25 33
Rated output
voltage (V)
3-phase 200 to 240 VAC (according to the input voltage)
Max. output
frequency
400 Hz parameter setting
