2-1 Installation
2-1-1 Dimensions
D 3G3MV-A2001 to 3G3MV-A2007 (0.1 to 0.75 kW) 3-phase 200-VAC Input
3G3MV-AB001 to 3G3MV-AB004 (0.1 to 0.4 kW) Single-phase 200-VAC
Input
Rated voltage Model 3G3MV-
Dimensions (mm)
Weight (kg)
R
a
t
e
d
v
o
l
t
a
g
e
M
o
d
e
l
3
G
3
M
V
-
D t
W
e
i
g
h
t
(
k
g
)
3-phase 200 VAC
A2001 76 3 Approx. 0.6
3
-
p
h
a
s
e
2
0
0
V
A
C
A2002 76 3 Approx. 0.6
A2004 108 5 Approx. 0.9
A2007 128 5 Approx. 1.1
Single-phase
2
0
0
V
A
C
AB001 76 3 Approx. 0.6
S
i
n
g
l
e
-
p
h
a
s
e
200 VAC
AB002 76 3 Approx. 0.7
AB004 131 5 Approx. 1.0
Design Chapter 2

Omron SYSDRIVE 3G3MV Specifications

General

Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1-400 Hz
Cooling Method	Forced Air Cooling
Communication Interface	RS-485
Model	Omron SYSDRIVE 3G3MV
Protection	Overcurrent, Overvoltage, Overheat
Ambient Temperature	-10 to 50°C
Overload Capacity	150% for 60 seconds
Storage Temperature	-20 to 65°C
Humidity	20 to 90% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	200-230V, 380-460V
