2-5
D 3G3MV-A2055 to 3G3MV--A2075 (5.5 to 7.5kW) 3-phase 200-VAC Input
3G3MV-A4055 to 3G3MV--A4075 (5.5 to 7.5kW) 3-phase 400-VAC Input
Two, 6 dia.
Rated voltage Model 3G3MV- Dimensions D
(mm)
Weight (kg)
3-phase 200 VAC A2055 170 Approx. 4.6
3-phase 200 VAC A2075 170 Approx. 4.8
3--phase 400 VAC A4055 170 Approx. 4.8
3--phase 400 VAC A4075 170 Approx. 4.8
Design Chapter 2
