9-21
H Applicable Models and Dimensions
D 200-V Class
Max. applicable motor
capacity (kW)
Model
3G3IV-PUZBABj
Current (A) Inductance (mH) Loss (W) Weight (kg)
0.1 to 0.2 2A7.0MH 2 7.0 8 2.5
0.4 2.5A4.2MH 2.5 4.2 15 2.5
0.75 5A2.1MH 5 2.1 15 2.5
1.5 10A1.1MH 10 1.1 25 3
2.2 15A0.71MH 15 0.71 30 3
4.0 20A0.53MH 20 0.53 35 3
5.5 30A0.35MH 30 0.35 45 3
7.5 40A0.265MH 40 0.265 50 4
Model
3
G
3
I
V
-
P
U
Z
B
A
B
j
Dimension (mm)
M
o
d
e
l
3G3IV-PUZBABj
A B B1 C D E F H J K L M
2A7.0MH 120 71 --- 115 40 50 105 20 M6 10.5 7 M4
2.5A4.2MH 120 71 --- 120 40 50 105 20 M6 10.5 7 M4
5A2.1MH 120 71 --- 120 40 50 105 20 M6 10.5 7 M4
10A1.1MH 130 88 --- 130 50 65 130 22 M6 11.5 7 M4
15A0.71MH 130 88 --- 130 50 65 130 22 M6 11.5 7 M4
20A0.53MH 130 88 114 105 50 65 130 22 M6 11.5 7 M5
30A0.35MH 130 88 119 105 50 70 130 22 M6 9 7 M5
40A0.265MH 130 98 139 105 50 75 130 22 M6 11.5 7 M6
D 400-V Class
Max. applicable motor
capacity (kW)
Model
3G3IV-PUZBABj
Current (A) Inductance (mH) Loss (W) Weight (kg)
0.2 to 0.4 1.3A18.0MH 1.3 18.0 15 2.5
0.75 2.5A8.4MH 2.5 8.4 15 2.5
1.5 5A4.2MH 5 4.2 25 3
2.2 7.5A3.6MH 7.5 3.6 35 3
3.0 to 4.0 10A2.2MH 10 2.2 43 3
5.5 15A1.42MH 15 1.42 50 4
7.5 20A1.06MH 20 1.06 50 5
Specifications Chapter 9
