10-21
Para
me-
ter
No.
Ref-
er-
ence
page
Chan-
ges dur-
ing
opera-
tion
Defaul
t set-
ting
Unit
of
set-
ting
Set-
ting
range
DescriptionNameReg-
ister
No.
n108 016C Motor leak-
age induc-
tance
Set the leakage inductance of the motor in use.
Note This parameter is used as a vector con-
trol constant.
Note TheInverterwiththedefaultsettinginthis
parameter fully functions in vector con-
trol.
0.00
to
655.0
0.01
mH
Varies
with
the
capac-
ity.
No 6-2
n109 016D Torque
compensa-
tion limit
Set a limit on the torque compensation function
in vector control mode.
Note Normally, the default setting does not
need to be changed.
Note TheInverterintorquecompensationcon-
trollimitsthetorqueatacurrent1.5times
larger than the set value.
0 to
250
1% 150 No 6-3
n110 016E Motor no-
load cur-
rent
Used to set the no-load current of the motor in
use based on the rated motor current as 100%.
Note Used as the constant of vector control
and the slip compensation function.
0 to
99
1% Varies
with
the
capac-
ity
No 5-6
n111 016F Slip com-
pensation
gain
Used to set the gain of the slip compensation
function.
Note The default is set to 1.0 in vector control
mode.
Note The slip compensation function is dis-
abled with n66 set to 0.0.
0.0 to
2.5
0.1 0.0 Yes 6-39
n112 0170 Slip com-
pensation
primary
delay time
Used for the response speed of the slip
compensation function.
Note The default is set to 0.2 in vector control
mode.
Note The default setting does not need any
changes in normal operation.
0.0 to
25.5
0.1 s 2.0 No 6-39
n113 0164 Slip com-
pensation
during
regenera-
tion
Selects the slip compensation function in
regenerative operation.
0: Disabled
1: Enabled
Note Thisparameterisvalidonlyinvectorcon-
trol mode.
0, 1 1 0 No 6-40
n114 Not used --- --- --- --- --- ---
List of Parameters Chapter 10
