Omron SYSDRIVE 3G3MV - Page 45

2-22
Model
3G3MV-
Molded-
case
circuit
breaker
capac-
ity (A)
Recom-
mended
wire
size
(mm
2
)
Wire
size
(mm
2
)
Screw
tighten-
ing
torque
(NSm)
Termi-
nal
screw
Terminal symbol
A2007
R/L1, S/L2, T/L3, B1, B2,
--, +1, +2, U/T1, V/T2,
W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 10
A2015
R/L1, S/L2, T/L3, B1, B2,
--, +1, +2, U/T1, V/T2,
W/T3
M4 1.2 to 1.5 2 to 5.5
2
20
3.5
A2022
R/L1, S/L2, T/L3, B1, B2,
--, +1, +2, U/T1, V/T2,
W/T3
M4 1.2 to 1.5 2 to 5.5 3.5 20
A2040
R/L1, S/L2, T/L3, B1, B2,
--, +1, +2, U/T1, V/T2,
W/T3
M4 1.2 to 1.5 2 to 5.5 5.5 30
A2055
R/L1, S/L2, T/L3, B1, B2,
--, +1, +2, U/T1, V/T2,
W/T3
M5 2.5 5.5 to 8 8 50
A2075
R/L1, S/L2, T/L3, B1, B2,
--, +1, +2, U/T1, V/T2,
W/T3
M5 2.5 5.5 to 8 8 60
D Single-phase 200-VAC Model
Model
3G3MV-
Terminal symbol Termi-
nal
screw
Terminal
torque
(NSm)
Wire
size
(mm
2
)
Recom-
mended
wire
size
(mm
2
)
Circuit
breaker
capac-
ity (A)
AB001
R/L1, S/L2, T/L3, B1, B2,
--, +1, +2, U/T1, V/T2,
W/T3
M3.5 0.8 to 1.0 0.75 to 2 2 5
