D Braking Resistors and Braking Resistor Units for 400-V-class Inverters
Inverter
3G3MV-
Braking Resistor
(3% usage rate ED)
3G3IV-
Braking Resistor Unit
(10% usage rate ED)
3G3IV-
Minimum
connection
resistance
A4002
PERF150WJ751 (750 W) PLKEB40P7 (750 W, 70 W) 750 W
A4004
P
E
R
F
1
5
0
W
J
7
5
1
(
7
5
0
W
)
P
L
K
E
B
4
0
P
7
(
7
5
0
W
,
7
0
W
)
7
5
0
W
A4007 510 W
A4015 PERF150WJ401 (400 W) PLKEB41P5 (400 W, 260 W) 240 W
A4022 PERF150WJ301 (300 W) PLKEB42P2 (250 W, 260 W) 200 W
A4030 PERF150WJ401 (400 W) ´ 2 PLKEB43P7 (150 W, 390 W) 100 W
A4040 PERF150WJ401 (400 W) ´ 2 PLKEB43P7 (150 W, 390 W) 100 W
A4055 PERF500WJ360T (36 W) PLKEB45P5 (100 W, 520 W) 32 W
A4075 PERF101WJ360T (36 W) PLKEB47P5 ( 75 W, 780 W) 32 W
Note Donotuseresistancesless than thantheminimumconnection resistancevalue.
Doing so may damage the Inverter.
Note The usage rate is shown as a percentage of the braking time in one cycle. If one
cycleis10seconds,forexample,onesecondofbrakingispossibleusingaBrak-
ing Resistor Unit (10% usage rateED). If the usagerate is tobeexceeded, a de-
tailed regeneration energy calculation will be required.
D The dimensions of a Braking Resistor Unit
Model No.
3
G
3
I
V
-
Dimensions (mm)
Weight
(
k
g
)
M
o
d
e
l
N
o
.
3G3IV-
A B C D Mounting Screws
W
e
i
g
h
t
(kg)
PLKEB40P7 105 275 50 260 M5x3 3.0
PLKEB41P5 130 350 75 335 M5x4 4.5
PLKEB42P2 130 350 75 335 M5x4 4.5
PLKEB43P7 130 350 75 335 M5x4 5.0
PLKEB45P5 250 350 200 335 M6x4 7.5
PLKEB47P5 250 350 200 335 M6x4 8.5
