95
Comparing the 8-Digit Counter (F) Present Value Using 8-Digit Comparators (G)
Section 3-12
Refer to page 25 for parameter setting methods.
3-12-3 Parameter Monitor Screen Display
Comparison item 8-Digit counter (F0)
Comparison data Constant: 00000000 to 99999999
Operator >=: Comparator bit turns ON when 8-digit counter present value ≥
Comparison data.
<=: Comparator bit turns ON when 8-digit counter present value
≤
Comparison data.
Monitor enabled/
disabled
A Operating parameters can be monitored.
D Operating parameters cannot be monitored.
G0 A
F0 123456789●
>=
12000000
• Example for 8-Digit Counter ≥ 12000000
8-Digit counter present value
8-Digit comparator bit status
( : OFF/●: ON)
