119
Appendix A
Specifications
Ratings
Item Specifications
ZEN-@C@AR-A-V2/ZEN-8E1AR ZEN-@C@D@-D-V2/ZEN-8E1D@
Power supply voltage 100 to 240 VAC, 50/60 Hz 12 to 24 VDC (ripple: 5% max.)
Rated power supply
voltage
85 to 264 VAC, 47/63 Hz 10.8 to 28.8 VDC
Power consumption
(1) CPU Units without Expansion I/O
Units
• ZEN-10C1AR-A-V2
/ZEN-10C2AR-A-V2
/ZEN-10C3AR-A-V2
100 V AC: 5 VA max.
240 V AC: 7 VA max.
• ZEN-10C4AR-A-V2
100 V AC: 6 VA max.
240 V AC: 8 VA max.
• ZEN-20C
@AR-A-V2
100 V AC: 7 VA max.
240 V AC: 10 VA max.
(2) CPU Units with three Expansion I/O
Units
• ZEN-10C1AR-A-V2
/ZEN-10C2AR-A-V2
100 V AC: 6 VA max.
240 V AC: 8 VA max.
• ZEN-10C4AR-A-V2
100 V AC: 7 VA max.
240 V AC: 9 VA max.
• ZEN-20C
@AR-A-V2
100 V AC: 8 VA max.
240 V AC: 11 VA max.
(3) Expansion I/O Units
ZEN-8E1AR
100 V AC: 3 VA max.
240 V AC: 4 VA max.
(1) CPU Units without Expansion I/O
Units
•ZEN-10C
@DR-D-V2
12/24 V DC: 3 W max.
(ZEN-10C3DR-D-V2: 2.8 W max.)
•ZEN-10C
@DT-D-V2
12/24 V DC: 2 W max.
•ZEN-20C@DR-D-V2
12/24 V DC: 4 W max.
•ZEN-20C
@DT-D-V2
12/24 V DC: 2 W max.
(2) CPU Units with three Expansion I/O
Units
•ZEN-10C
@DR-D-V2
12/24 V DC: 4 W max.
•ZEN-10C
@DT-D-V2
12/24 V DC: 3 W max.
•ZEN-20C@DR-D-V2
12/24 V DC: 5 W max.
•ZEN-20C
@DT-D-V2
12/24 V DC: 3 W max.
(3) Expansion I/O Units
• ZEN-8E1DR
12/24 V DC: 2 W max.
Inrush current ZEN-10C@AR-A-V2: 4.5 A max.
ZEN-20C@AR-A-V2: 4.5 A max.
ZEN-8E1AR: 4 A max.
ZEN-10C@D@-D-V2: 30 A max.
ZEN-20C@D@-D-V2: 30 A max.
ZEN-8E1DR: 15 A max.
Ambient temperature 0 to 55°C
(–25 to 55°C for LED type CPU Units)
Ambient humidity 10% to 90% (with no condensation)
Storage temperature –20 to 75°C
(–40 to 75°C for LED type CPU Units)
Terminal block Tightening torque: 0.565 to 0.6 N⋅m (5 to 5.3 in-lb)
Degree of protection IP20 (Mounted inside a control panel)
Z211-E1-03.book Page 119 Friday, November 21, 2008 10:38 AM
