Wiring Section 2-2
2-2-2 Connectable Wires
Note When using a 2-line connection, use wires of the same size for
both lines.
• Strip the sheath back 6.5 mm.
Note When using a 2-line connection, use terminals of the same size
for both lines.
• Use a flat-blade screwdriver to tighten the terminal block screws
and tighten the screws to a torque of 0.565 to 0.6 N·m (5 to 5.3
in-lb).
• Recommended screwdriver: SZS0.6X3.5 or SZF1-0.6X3.5
manufactured by Phoenix Contact
2-2-3 Wiring Power Supply and Input Lines
Precautions for Correct Use
• Do not use terminals that are not connected as relay terminals.
One-line connection
0.2 to 2.5 mm
2
(Equivalent to AWG24 to AWG14)
Two-line connection
0.2 to 0.75 mm
2
(Equivalent to AWG24 to AWG19)
6.5 mm
CAUTION
Fires may occasionally occur. Tighten the terminal block screws to a
torque of 0.565 to 0.6 N·m (5 to 5.3 in-lb).
Z211-E1-03.book Page 40 Friday, November 21, 2008 10:38 AM

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
