Omron ZEN User Manual

157
Appendix F
Allocations and Setting Table
I/O Allocations for the ZEN-10C@@@-@-V2
* Output bit Q3 of CPU Units with communications cannot be output externally. It can be
used as a work bit.
I/O Unit name Bit Input device name Input IN filter
Input
bits
CPU Unit I0 AC DC V Yes No
I1
I2
I3
I4 Normal input AC DC V Yes No
Analog voltage input
I5 Normal input
Analog voltage input
Expansion
I/O Unit
X0 AC DC V Yes No
X1
X2
X3
Expansion
I/O Unit
X4 AC DC V Yes No
X5
X6
X7
Expansion
I/O Unit
X8 AC DC V Yes No
X9
Xa
Xb
I/O Unit name Bit Output device name and specifications
Output
bits
CPU Unit Q0 AC DC V A
Q1 AC DC V A
Q2 AC DC V A
Q3* AC DC V A
Expansion
I/O Unit
Y0 AC DC V A
Y1 AC DC V A
Y2 AC DC V A
Y3 AC DC V A
Expansion
I/O Unit
Y4 AC DC V A
Y5 AC DC V A
Y6 AC DC V A
Y7 AC DC V A
Expansion
I/O Unit
Y8 AC DC V A
Y9 AC DC V A
Ya AC DC V A
Yb AC DC V A
CPU Unit IN I0 to I5
Expansion I/O Unit IN X0 to Xb
(Bits allocated in order of connection.)
Expansion I/O Unit OUT Y0 to Yb
(Bits allocated in order of connection.)
CPU Unit OUT Q0 to Q3
Z211-E1-03.book Page 157 Friday, November 21, 2008 10:38 AM

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
