47
Wiring Section 2-2
Precautions for Safe Use
• Supply power to both the CPU Unit and Expansion I/O Units
from the same power supply and turn them ON and OFF at the
same time.
• Expansion I/O Units with AC inputs (ZEN-8E1AR) cannot be
connected to a CPU Unit with a DC power supply.
Precautions for Correct Use
• The input common for Expansion I/O Units with relay outputs
(ZEN-8E1DR) is internally connected to one side of the power
supply circuit (COM terminal).
• A power supply does not need to be connected to Expansion I/O
Units with transistor outputs (ZEN-8E1DT).
Z211-E1-03.book Page 47 Friday, November 21, 2008 10:38 AM

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
