Setting Measurement Items

ZFX-C User’s Manual

Possible output results

The following values can be output when expressions are set.

For details on reference position, Position difference p.50

Item Description Message

Judgment result The judgment result is output. (0:OK, -1:NG, -2: not measured) Judge (JG)

Area The area of the measurement target color is output.

(0 to 9999999.999)

Area (AR)

Gravity position The X, Y coordinates of the gravity of the measurement target color

are output. (-9999.999 to 9999.999)

Gravity X, Y

(X, Y)

Axis angle The angle of the measurement target color is output.

(-90.0 to 90.0)

Axis angle (TH)

Reference area The area when the measurement region is set is output.

(0 to 9999999.999)

Ref. area (SA)

Reference position The X, Y coordinates of the gravity when the measurement region is

set are output. (-9999.999 to 9999.999)

Reference X, Y

(SX, SY)

Reference axis angle The angle when the measurement region is set is output.

(-90.0 to 90.0)

Ref. axis angle

(ST)

Area difference The area difference obtained by "measurement value - reference

value" is output. (-9999999.999 to 9999999.999)

Area dif. (DA)

Position difference The position difference obtained by "gravity position - reference

position" is output. (-9999.999 to 9999.999)

Position dif. X, Y

(DX, DY)

Axis angle difference The axis angle difference obtained by "measurement value -

reference value" is output. (-180.0 to 180.0)

Axis angle dif.

(DT)
