Chapter 4 - Technical Specification
4.1.4 Review client properties
Browser-based review clients let you review and analyze patient images.
TABLE 9: Review client properties
Review clients
Display properties for browser-based review clients.
The minimum recommended monitor resolution. 1280 x 1024 pixels, 16.7 million colors.
Recommended browsers for OptosAdvance.
Google Chrome (46.0 and higher)
Internet Explorer (11.0 and higher)
Apple Safari (6.0 and higher)
4.1.5 Touch screen properties
The touch screen is powered from the scan head at +12V.
WARNING
Do NOT disconnect or connect the touch screen while the scan head is in use.
TABLE 10: Touch screen properties
Dimension Details
Minimum display resolution 1024 x 768 pixels, 16.7 million colors
Width 260 mm (10.5 inches)
Depth 20îmm (1 inch)
Height 216 mm (8.5 inches)
Weight less than 1 kg
Touch screen mount VESA MIS-D, 75, C (hole pattern: 75 mm x 75 mm)
4.1.6 Table requirements
WARNING
DoîNOT plug the scan head into a power block or powered table. The scan head must be
plugged directly into a wall socket.
The scan head should be positioned in the middle of the table width. The front of the scan
head should be inline with the front of the table to allow the patient to get into the correct
alignment position.
The chin rest should slightly overhang the edge of the table.
The scan head and touch screen must be positioned on a table that meets the necessary safety standards. The
table MUST support the weight of the scan head.
TABLE 11: Table size requirements
Dimension Details
Width 887 mm (35 inches)
Depth 600 mm (24 inches) including chin rest
Height 725 mm (29 inches) to 1205 mm (47 inches)
Part Number: G108707/8GME Page 65 of 75
Copyright 2018, Optos plc. All rights reserved. English
