Patient Alignment Guide
Too far out
(Used for optomap alignment)
Correct positioning
Helpful tip: Stay still and keep looking at the center of the cross hairs. Keep
both eyes wide open.
(Used for optomap and OCT alignment)
Too close
(Used for optomap alignment)
Note: In some instances the operator may choose to capture an image when you are aligned to the blue or red
target. When capturing OCT modalities the operator may choose to capture an image when you are aligned slightly
off center.
Part Number: G108707/8GME Page 75 of 75
Copyright 2018, Optos plc. All rights reserved. English
