Oracle Netra SPARC T4-1B User Manual

2 Netra SPARC T4-1B Server Module Service Manual • June 2012
No. FRU FRU Name (If Applicable) Links
1 DIMMs /SYS/MB/CMP0/BOBn/CHn/Dn “Servicing Memory” on page 75
2 Rear connector cover Remove before inserting the server module in a slot.
3 ID PROM /SYS/MB/SCC “Servicing the ID PROM” on page 101
4 USB flash drive “Servicing a USB Flash Drive” on page 105
5 Clock battery /SYS/MB/BAT “Servicing the Battery” on page 109
6 Drive (HD or SSD) /SYS/HDDn “Servicing Drives” on page 65
7 Drive filler “Servicing Drives” on page 65
8 Enclosure assembly /SYS/MB “Replacing the Server Module Enclosure Assembly
(Motherboard)” on page 113
9SP /SYS/MB/SP “Servicing the SP Card” on page 97
10 REM /SYS/MB/REM “Servicing the REM” on page 89
11 FEM /SYS/MB/FEM “Servicing the FEM” on page 93

Oracle Netra SPARC T4-1B Specifications

General

Brand	Oracle
Model	Netra SPARC T4-1B
Category	Server
Language	English
