78 Netra SPARC T4-1B Server Module Service Manual • June 2012
DIMM configuration guidelines:
■ Use only supported industry-standard DDR-3 DIMMs.
■ Use supported DIMM capacities: 4 Gbyte, 8 Gbyte, and 16 Gbyte.
Refer to the Netra SPARC T4-1B Server Module Product Notes for the latest
information.
■ Install quantities of 4, 8, or 16 DIMMs, in the correct slots:
■ 4 DIMMs: CH1/D0 slots (white sockets)
■ 8 DIMMs: CH1/D0 and CH0/D0 slots
■ 16 DIMMs: All slots
■ Ensure that all DIMMs have the same part number.
Related Information
■ “Memory Faults” on page 75
■ “Locate a Faulty DIMM” on page 79
■ “Remove a DIMM” on page 80
■ “Install a DIMM” on page 81
■ “Clear the Fault and Verify the Functionality of the Replacement DIMM” on
page 82
5 DIMMs controlled by BOB0:
CH0/D1
CH0/D0
CH1/D1
CH1/D0
6 DIMMs controlled by BOB1:
CH1/D0
CH1/D1
CH0/D0
CH0/D1
7 DIMM Fault LEDs
No.
Description or Partial FRU Name
(full names star t with /SYS/MB/CMP0/)
