Configure RAID in UEFI Boot Mode

Note - Alternatively, you can select the Create Virtual Drive option, which provides a RAID

configuration wizard with no advanced settings.

Select the Select RAID Level option, and then press Enter.

124 Oracle Server X5-2 Installation Guide • January 2021
