Oracle X5-2 User Manual

Configure the Preinstalled Oracle VM Server
■
To display output to the video port (default option), select the first option in the list and
press Enter:
Oracle VM Server - ovs (xen-4.3.0 3.8.13-26.4.2.e16uek.x86_64)
■
To display output to the serial port, select the second option in the list and press Enter:
Oracle VM Server - ovs serial console (xen-4.3.0 3.8.13-26.4.2.e16uek.
x86_64)
As the configuration process begins, the following screen appears:
6.
Scroll down the screen and set and confirm the root password and the Oracle VM
Agent password.
Note - The prompts for the root and the Oracle VM Agent passwords are only displayed the
first time you boot the Oracle VM Server.
7.
Follow the prompts to select the on-board network interface controller (NIC) to
configure, and then enter other required configuration information related to the
network.
Configuring the Preinstalled Oracle VM Server Software 149

Oracle X5-2 Specifications

General

Number of Processors	2
Cores per Processor	Up to 18
Form Factor	2U Rackmount
Processor	Intel Xeon E5-2600 v3
Memory	Up to 768 GB DDR4
Power Supply	1200W
Operating System	Oracle Linux, Oracle Solaris
Network	4 x 10Gb Ethernet ports
