Oracle X5-2 User Manual

Install the Shipping Bracket With Cable Trough (Optional)
b.
Retrieve a cage nut and hook the bottom lip of the cage nut in one of the rail
holes.
c.
Insert the tip of the cage nut insertion tool through the rail hole and hook the
top lip of the cage nut. [2]
d.
Using the insertion tool, pull the cage nut through the hole until the top lip
snaps into place.
e.
Repeat Step 2a through Step 2d for the remaining cage nuts.
56 Oracle Server X5-2 Installation Guide • January 2021

Oracle X5-2 Specifications

General

Number of Processors	2
Cores per Processor	Up to 18
Form Factor	2U Rackmount
Processor	Intel Xeon E5-2600 v3
Memory	Up to 768 GB DDR4
Power Supply	1200W
Operating System	Oracle Linux, Oracle Solaris
Network	4 x 10Gb Ethernet ports
