V–11
5) Data setting operation (Level 2)
Setting start operation method : Press the SET (S007) key for one second in the setting data code select
mode.
This activates the forced setting in progress display. (TEST/WARNING
LED light)
Setting change operation method : After entering the setting start operation mode, operating the UP (S005)
and DOWN (S006) keys make it possible to change the setting details
of the selected setting categories.
Setting confi rm operation method : After entering the setting start operation or setting change operation
completed, press the SET (S007) key for one second.
This cancels the forced setting in progress display, making it possible to
once again enter setting item selection operation mode.
(TEST/WARNING LED off)
Setting cancel operation method : Press the HOME (S004) key for one second before confi rming setting.
This returns operation to normal. (TEST/WARNING LED off)
The setting details will not change when pressing the HOME (S004) key for one second during setting item
select operation.)
Data setting operation is possible from items No. 0 to No. 8.
The following data is displayed.
Data
code
Measurement item
Display
examples
Standard operation data
Data name Unit
During cooling
operations
During heating
operations
1 Engine operation time Hrs
2Engine operation count Times
3 Starter operation time Seconds
4 Starter operation count Times
5 Current oil change time Hrs
6
7
8
9
A
b
c
d
E Clutch on time Hrs
F Clutch on count Times
G Clutch 2 on time Hrs
H Clutch 2 on count Times
i
J
K
L
n
o
P Oil error time Hrs
q
10 Engine revolution setting min
-1
600~2200
11 Engine revolutions min
-1
600~2200
12 Compressor inlet pressure MPa
0.60~0.90 0.30~1.10
13 Compressor outlet pressure MPa
2.30~3.20 2.40~3.30
14 Compressor inlet temperature °C
5~30 0~30
15 Compressor outlet temperature °C
70~110 80~110
16
Outdoor unit heat exchange inlet
temperature
°C
30~50 -5~10
