Panasonic 2WAY Multi - Page 136

V–17
Data
code
Data name Unit
Display
examples
Remarks
o
P
q
10 Engine revolution setting min
-1

2,200 min
-1
11 Engine revolutions min
-1

2,200 min
-1
12 Compressor inlet pressure Mpa

0.10 MPa
13 Compressor outlet pressure MPa

1.00 MPa
14 Compressor inlet temperature °C

35.0°C
15 Compressor outlet temperature °C

110.0°C
16
Outdoor unit heat exchange inlet
temperature
°C

45.0°C
17
Outdoor unit heat exchange 2 inlet
temperature (3WAY only)
18
19
20 Refrigerant temperature °C

65.0°C
21 Outside air temperature °C

28.0°C
22 Clutch coil temperature °C

50.0°C
23 Catalyst temperature °C

250.0°C
24 Hot water outlet temperature (optional) °C

70.0°C
25
26
Oil level measurement temperature
(W-Multi)
°C

54.0°C
27
28
29
30
31 Clutch coil 2 temperature °C

50.0°C
32
33
34 Exhaust gas temperature °C

65.0°C
35
36
37
38 Outdoor unit fan 1 %

100%
39 Outdoor unit fan 2 %

100%
40
41 Outdoor unit fan revolutions 1 min
-1

650 min
-1
42 Outdoor unit fan revolutions 2 min
-1

650 min
-1
43
44 Coolant pump setting min
-1

3,700 min
-1
45 Coolant pump revolutions min
-1

3,700 min
-1
46 Throttle Step

100 steps
47 Fuel gas regulating valve Step

330 steps
48 Liquid valve Step

220 steps
49 Bypass valve Step

100 steps
50 Outdoor unit solenoid valve 1 Step

480 steps
51 Outdoor unit solenoid valve 2 Step

480 steps
52 Three-way coolant valve Step

1,950 steps
53 Exhaust heat collection valve Step

200 steps
54
Three-way hot water extraction valve
(optional)

50 steps
