V–62
6) Loop wiring is prohibited. (Figure 8)
Example: As shown in the gure, do not have wiring where part of it is looped or the entire wiring is
looped.
Outdoor unit
Indoor unit
Indoor unit
No remote controller
Group control
Indoor unit
Remote controller
Controller
Outdoor unit
Outdoor unit
Indoor unit
Indoor unit
Indoor unit
Indoor unit
Indoor unit
Indoor unit
Remote controller
Remote controller
Note:
--- indicates the
looped portion.
(Figure 8)
7) Daisy chain system (Figure 9)
Controller
Outdoor unit
Indoor unit Indoor unit Indoor unit
Remote controller
(Figure 9)
GHPtroubleshooting.indbV‒62GHPtroubleshooting.indbV‒62 2012/11/2611:20:282012/11/2611:20:28
