Panasonic Firetracker FT128 - Sensor Values (H4;U3)

Operation Manual
FT128 Rev 2.4
102
23.3 Sensor Values (H4/U3)
Information on heat, smoke or multi detector sensor values. XX.X%/m = XX.X %
obscuration per meter".
Perf. Factor: see below this table. nnnnnn = algorithm short name.
No. of months left: the number of months until the detector activates service signal. See
section 23.3.1 “Explanation of the Sensor Values” below.
Text in display Comments
"Access" Log on to FT128 as shown
in page 35.
Scroll to menu H4. Present system status
ACCEPT? H4
"A"
Disablement
ACCEPT? U1
Scroll to menu U3.
Sensor values
ACCEPT? U3
Press "A" to accept.
"A" Start Sensor : 00-00 Write the presentation
number and/or press "A"
to accept.
Depending
on the type,
the following
will be
shown
(examples):
"A"
Type Analogue multi 4300/4400 in Normal mode:
This is a list in which you
can scroll or use "" to
see the next information
window for the selected
sensor.
Press "Return" back to
"Start Sensor...".
Scroll or write a new
presentation number or
press "Return" to menu
U3.
Note: XX.X%/m = XX.X %
obscuration per meter".
Perf. Factor: see below
this table.
nnnnnn = algorithm short
name, see separate table,
page 103.
Sensor: 01-01 (technical address AAA)
Momentary: XX.X%/m Weekly: XX.X%/m
""
Sensor: 01-01 Min: XX.X%/m
Perf factor: X.XX%/m Max: XX.X%/m
""
Sensor: 01-01
Current Algorithm: nnnnnn
"A"
Type Analogue heat 3308/3309 in Normal mode:
Sensor: 01-02 (technical address AAA)
Momentary: XX°C Min: XX°C Max: XX°C
""
Sensor: 01-02
Current Algorithm: nnnnnn
"A"
Type Analogue Multi 4400 in Advanced Mode:
Sensor: 01-01 (technical address AAA)
Momentary: XX.X%/m Weekly: XX.X%/m
""
Sensor: 01-01 Min: XX.X%/m
Perf Factor: X.XX%/m Max: XX.X%/m
""
Sensor: 01-01
Current Algorithm: nnnnnn
"" Sensor: 01-02 (technical address AAA)
Momentary: XX°C Min: XX°C Max: XX°C
""
Sensor: 01-02
Current Algorithm: nnnnnn
