24.1 Calibration of Supervised Outputs (H5/A1)
Supervised (monitored) outputs
64
:
• The voltage outputs (S0-S1) in the control unit
• The voltage outputs (VO0-VO1) in the COM loop output unit 3364.
• The voltage outputs (Output 0-Output 1) on the I/O expansion board 4583
When all alarm devices (OWS, sounders, etc.) are connected, including required End-Of-
Line devices
65
and when the SSD download is ready, a calibration has to be done.
Function: If the actual value differs from the calibrated value ± a small tolerance or if the
calibrated value is outside the calibration range
66
, a fault will be generated.
Action Text in display Comments
"Access"
Log on to FT128 as shown
in page 35.
Scroll to menu H5
Service
ACCEPT? H5
"A"
Calibration of supervised outputs
ACCEPT? A1
"A"
To calibrate supervised outputs press
ACCEPT
"A"
Calibration in progress
Please wait......
"A"
Calibration is completed
ACCEPT?
"A"
Calibration of supervised outputs
ACCEPT? A1
Scroll or press "Return" to
H5.
Service
ACCEPT? H5
Scroll or press "Return"
Note: During the calibration, all outputs will automatically be low, i.e. a normally high
output will be low during the calibration for a few seconds.
Note: After the calibration it is recommended to do a "Safe shutdown of control unit" (see
menu H8/S4). This will save the SSW data (e.g. the calibration values) in a Flash ROM
(see page 82).
64
Supervised (monitored) outputs can be set to be not supervised via EBLWin.
65
FT128 outputs (S0-S1) requires one EOL resistor (33K) in the last unit or one resistor (33K) in up to five units, 3364 outputs
(VO0-VO1) requires one EOL capacitor (470 nF) in the last unit or one capacitor (470 nF) in up to five units.
66
4K7 – 50K and 470 – 5x470 nF respectively.
