27.8 Activate Zone-Address in Alarm Mode (H8/S8)
One alarm point (zone-address), not a whole zone, can be manually set in alarm mode. It
will be presented as a fire alarm, the built-in LED in the alarm point (for example a detector)
will be turned on and all outputs, standard and programmable, which would have been
activated by a normal fire alarm from the same alarm point will be activated.
Note: A detector programmed for "Quiet alarm" will activate a Quiet alarm instead of a
fire alarm.
Action Text in display Comments
"Access" Log on to FT128 as shown in
page 35.
Scroll to menu H8. Maintenance
ACCEPT? H8
"A" Acknowledge SERVICE signal
ACCEPT? S1
Scroll to menu S8. Activate zone/address in alarm mode
ACCEPT? S8
"A" Select zone: 00 address: 00
ACCEPT?
Write the zone and
address e.g. "12-45"
Select zone: 12 address: 45
ACCEPT?
Press "A" to accept /
activate the fire alarm.
"A"
001 ZONE-ADDR 12-45 LAST ZONE 12 No. 01
"Alarm text for 12-45"
Normal fire alarm
presentation in the FT128.
If more alarm points have to
be set in alarm status,
press "Return" to select
another zone - address and
continue as above.
"Return"
Select zone: 00 address: 00
ACCEPT?
Write another zone
and address, e.g.
"12-34".
Select zone: 12 address: 34
ACCEPT?
Press "A" to accept / start
the fire alarm.
"A"
"Alarms queued"
001 ZONE-ADDR 12-45 LAST ZONE 12 No. 01
"Alarm text for 12-45"
The LEDs "Alarms queued"
(L2) are indicating that
more than one alarm point
is in alarm. Press the
button "Alarms queued"
(P1) to see the other alarm.
Press "Reset" to reset the
alarm(s).
002 ZONE-ADDR 12-34 LAST ZONE 12 No. 01
"Alarm text for 12-34"
