FAULT: Site specific data (SSD)
Date: DD-MM Time: HH:MM
The last message means that the SSD has not been successfully downloaded. A new
SSD download has to be performed.
19.4 Boot Menu
The Boot menu should be used by authorised personnel only!
Note: Vital data can be erased via this menu.
The Boot menu is opened as follows:
a) Perform a "cold restart", i.e. power down / power up FT128, the following text
messages will be shown in the FT128 display:
*** FT128 ***
Checking program memory......
b) And after that, for a second:
Booting......
c) When the text "Booting……" appears, press "Access" and 0.1 sec. later also
press "1" and the Boot menu will be shown:
1:Restart, 2:Erase memory
Press "1" to perform a restart (you will also leave the Boot menu).
Press "2" to open the Erase memory menu, see below.
The Erase memory menu:
1 = SSD, 2 = SSW, 3 = Texts
Press "1" to erase the SSD memory.
Press "2" to erase the SSW memory.
Press "3" to erase the texts memory.
Text "Erasing SSD", "Erasing SSW" and "Erasing texts" respectively will be shown and
then the Erase memory menu will be shown again.
Press "Return" to return to the Boot menu.
Note:
After erasing the SSW, perform a "Power down / power up" restart directly.
All other alternatives are strictly forbidden to use. These are used for troubleshooting
only and is controlled by Brooks engineers.
