24.5 Display Current Consumption on COM-Loop (H5/A5)
An average current consumption value can be displayed for the COM loop.
Note: No or very small current consumption (< 10mA) will not be presented correctly /
precisely since the accuracy is ± 5 mA.
Action Text in display Comments
"Access"
Log on to FT128 as shown
in page 35.
Scroll to menu H5.
Service
ACCEPT? H5
"A"
Calibration of supervised outputs
ACCEPT? A1
Scroll to menu A5 Display current consumption on
COM loop ACCEPT? A5
"A" Current consumption on COM-loop is
XXX mA ACCEPT?
"A" or
"Return"
Display current consumption on
COM loop ACCEPT? A5
Scroll or press "Return" to
H5.
"Return"
Service
ACCEPT? H5
Scroll or press "Return".
Note: Each window is updated continuously.
