28.4 Disable Interlocking Output (H9/C4)
Interlocking outputs (Type = Interlocking) can be individually disabled via this menu (and
collectively via menu H2/B3). The "Interlocking Combination" (Area / Point) is to be entered
to disable the output.
Up to 100 interlocking outputs can be disabled in the system.
Disabled interlocking outputs are listed in menu H4/U1.
The LED “Disablements” is also indicating one or more disabled interlocking outputs.
Re-enable is performed via menu H9/C5.
Action Text in display Comments
"Access"
Log on to FT128 as shown in
page 35.
Scroll to menu H9.
Interlocking outputs and inputs
ACCEPT? H9
"A"
Activated interlocking outputs/inputs
ACCEPT? C1
Scroll to menu C4.
Disable interlocking output
ACCEPT? C4
"A"
Disable interlocking output
area 00 point 00 ACCEPT?
e.g.: "01", "01"
"A"
Disable interlocking output
area 01 point 01 ACCEPT?
Press "A" to accept and/or
"Return" to menu C4.
"A"
interlocking output 01 – 01 disabled
"A"
Disable interlocking output
ACCEPT? C4
Scroll or press "Return" to
menu H9.
Scroll to menu H9.
Interlocking outputs and inputs
ACCEPT? H9
Scroll or press "Return"
