Operation Manual
FT128 Rev 2.4
135
28.2 Activate Interlocking Output (H9/C2)
The output in each interlocking combination (area / point) can be manually activated via
this menu. The corresponding interlocking input will be "monitored" in the same way as if
the output was activated by its control expression.
Reset has to be performed via menu H9/C3.
Action Text in display Comments
"Access"
Log on to FT128 as shown in
page 35.
Scroll to menu H9.
Interlocking outputs and inputs
ACCEPT? H9
"A"
Activated interlocking outputs/inputs
ACCEPT? C1
Scroll to menu C2.
Activate interlocking output
ACCEPT? C2
"A"
Activate interlocking output
area 00 point 00 ACCEPT?
e.g.: "01", "01"
“A”
Interlocking output 01-01 activated
“A”
Activate interlocking output
area 01 point 01 ACCEPT?
If more outputs shall be
activated do as above, else
press "Return" to menu C2.
"Return"
Activate interlocking output
ACCEPT? C2
Scroll or press "Return" to
menu H9.
"Return"
Interlocking outputs and inputs
ACCEPT? H9
Scroll or press "Return"
