Operation Manual
FT128 Rev 2.4
94
21.7 Re-Enable Output (H2/B7)
Disabled outputs are listed in menu H4/U1.
When all outputs have been re-enabled, the LED "Disablements" (L8) will be extinguished,
if there are no other disablements.
If there is nothing to re-enable, --- List is empty --- will be shown.
Action Text in display Comments
"Access" Log on to FT128 as shown in
page 35.
Scroll to menu H2. Disable or re-enable
ACCEPT? H2
"A" Disable zone
ACCEPT? B1
Scroll to menu B7. Re-enable output
ACCEPT? B7
"A"
Re-enable output type: 0
0=Loop unit 1=S 2=R0 3=EXPB ACCEPT?
Only disabled type(s) will be
shown. Press:
"0"=3361 or 4477 or 3379 or
3364 or 4380
"1"=FT128 output S0-S1
"2"=FT128 output R0
"3"=FT128 exp. board output
(4581).
Press "A" to accept.
Or, e.g. if only type 2 is disabled:
Re-enable output type: 0
2=R0 ACCEPT?
"0", "1", "2" or "3"
"A"
Depending on the
chosen type the
following will be shown:
Re-enable output 0 technical address 000
ACCEPT? L
Re-enable output S0
ACCEPT? L
Re-enable output R0
ACCEPT? L
Re-enable output 0 expansion board 0
ACCEPT? L
L=A list in which you can
scroll.
Regarding the 4477 & 3379
units' output no.:
0=high priority
1=medium priority
2=low priority
Press "A" to accept.
"A" --- List is empty ---
All types are re-enabled.
"Return" Re-enable output
ACCEPT? B7
If more re-enabling required
continue as above. If not,
scroll or press "Return" to
menu H2.
"Return" Disable or re-enable
ACCEPT? H2
Scroll or press "Return".
