Operation Manual
FT128 Rev 2.4
138
28.5 Re-Enable Interlocking Output (H9/C5)
Disabled interlocking outputs are listed in menu H4/U1.
Interlocking outputs (Type = Interlocking) will be re-enabled via this menu but not via menu
H2.
All interlocking outputs, disabled via menu H2/B4, will be re-enabled via menu H2/B8
If there are no outputs to re-enable, --- List is empty --- will be shown.
Action Text in display Comments
"Access"
Log on to FT128 as shown in
page 35.
Scroll to menu H9.
Interlocking outputs and inputs
ACCEPT? H9
"A"
Activated interlocking outputs/inputs
ACCEPT? C1
Scroll to menu C5.
Re-enable interlocking output
ACCEPT? C5
"A"
Re-enable interlocking output
area 00 point 00 ACCEPT?
This is a list in which you can
scroll.
Press "A" (for re-enable) or
"Return" (not re-enable) to menu
C5.
"A" or
"Return"
Re-enable interlocking output
ACCEPT? C5
Scroll or press "Return" to menu
H9.
"Return"
Interlocking outputs and inputs
ACCEPT? H9
Scroll or press "Return"
