27.9 Activate Output (H8/S9)
Via this menu, a loop unit output, control unit output and expansion board output can be
activated.
Any output can be activated, which means the function can be tested. (Can also be done
via EBLWin.) This is including Addressable siren 4477, Addressable sounder base 3379,
wireless detector 4611, light indicator 4383, and all alarm devices 4480, 4481, 4482, 4487.
The selected output will be activated no matter if the control expression is true or not. The
selected output will be reset only if the control expression is false. If the control expression
is true when you reset the output via menu H8/S10, the output will remain activated until
the control expression is false again.
Action Text in display Comments
Access
Log on to FT128 as shown in
page 35.
Scroll to menu H8. Maintenance
ACCEPT? H8
Acknowledge SERVICE signal
ACCEPT? S1
Scroll to menu S9.
Activate output
ACCEPT? S9
"A"
Activate output type: 0
0=Loop unit 1=S 2=R0 3=EXPB ACCEPT?
Loop unit=3361 or 3364
S=S0-S1, R0=R0
EXPB= 4581 or 4583
Depending on if 0,
1, 2 or 3 is selected
one of the
alternatives will be
shown.
Activate output: 0, technical address 000
Fill in the requested data
respectively and press "A".
Activate S0
ACCEPT?
Activate R0
ACCEPT?
Activate output: 0, expansion board 0
ACCEPT?
"A"
1, 2 or 3 is selected
one of the
alternatives will be
shown.
Output 0 technical address 002
forced active
Output S0 forced active
Output R0 forced active
Output 0 expansion board 0 forced active
"A"
"Return"
Activate output type: 0
0=Loop unit 1=S 2=R0 3=EXPB ACCEPT?
If more outputs shall be
activated do as above, else
press "Return" to menu S9.
Activate output
ACCEPT? S9
Scroll or press "Return" to
menu H8.
"Return"
Maintenance
ACCEPT? H8
Scroll or press "Return".
