Operation Manual
FT128 Rev 2.4
91
21.4 Disable All Control, Ventilation, Extinguishing or
Interlocking Outputs (H2/B4)
Outputs programmed as type Control (general), type Fire ventilation, type Extinguishing
system and type Interlocking can be collectively disabled for the type respectively (all at
the same time).
Disabled output means that even if the control expression (trigger condition) for the output
is true, the output will not be activated. Disabled outputs are shown in menu H4/U1.
The outputs will be disabled until re-enabled again (via H2/B8).
Action Text in display Comments
"Access"
Log on to FT128 as shown
in page 35.
Scroll to menu H2.
Disable or re-enable
ACCEPT? H2
"A"
Disable zone
ACCEPT? B1
Scroll to menu B4.
Disable all control, extinguishing, ventilation
or interlocking outputs ACCEPT? B4
"A" Disable type:0 0=Control 1=Ventilation
2=Exting 3=Interlocking ACCEPT?
Press:
"0"=control outputs
"1"= ventilation outputs
"2"= extinguishing output
"3"=interlocking outputs.
Press "A" to accept. LED
(L8) “Disablement” will
illuminate
“0”, “1”, “2” or “3”
"A"
Depending on
selected type, the
following will be
shown:
All xxxxxx outputs disabled
XXXXX=control,
ventilation, extinguishing or
interlocking.
"A"
Disable type: 0 0=control 1=ventilation
2=exting 3=Interlocking ACCEPT?
If more disablements
required, continue as
above otherwise, press
"Return" to menu B4.
"Return"
Disable all control, ventilation, exting.
or interlocking outputs ACCEPT? B4
Scroll or press "Return" to
menu H2.
"Return" Disable or re-enable
ACCEPT? H2
Scroll or press "Return"
